Features and Benefits:
- Everything you need to repair aluminum panels
- The most complete aluminum repair station from a name you know and trust!
- The capacitor discharge welder is 110 volt powered. Re-charge time for the capacitors is less than 3 seconds. The ground is on the weld gun itself
- The fact that we have two ground points on either side of the weld gun also leads to a more successful weld rate
- The DF-900DX includes everthing found in the DF-900A but also includes a bridge puller, 3rd drawer and dust cover
The most complete aluminum repair station “from a name you know and trust!”
” I mean it is very simple to use, its not Rocket Science. I am repairing aluminum panels that I would have just thrown away. “
Andrew Foote, 20 year shop owner and auto body technician
The idea here is that you have everything you need for aluminum repair,within easy reach in a self-contained system. The tools lock away sothey do not wander the shop and become contaminated with steelparticles.
As you probably know aluminum panel repair is a different process thanthat for steel panels. Aluminum is a softer material it stretcheseasily. That is why it is alloyed with magnesium or silicon in cosmeticpanels. We include two different alloys of stud pin for bonding with thevarious panels.
Aluminum is also work hardened; meaning when it is stamped into shape itbecomes stronger. When the panel is bent in a collision it becomesstronger still. Flex it too much and it breaks or cracks.
Sometimes in order to relieve this over-hardening and be able to pullthe damaged area needs to be heated the allow the metal to release. Thepanel must always be heated to about 400 degrees while under pull inorder for the panel to set in new position. Hence the inclusion of aninfrared thermometer and digital temperature set heat gun to heat thepanel. A self-locking squeeze puller makes it easier to pull and heat atthe same time. This squeeze puller can pull on one or several pins. Forheavier pulls a leverage puller and for lighter finesse pulls a singlepin hand puller are included.
Put steel particles into the aluminum panel and you will start theelectrolytic process of galvanic corrosion. The aluminum will corrodearound the steel contamination ruining the paint on your finished jobs.In order to avoid this a separate set of working tools must bemaintained. That is why we have included a separate set of hammers,dollies, and nylon shaping tools, body file, and an Air drive for 3MRoloc discs. Again the tools lock away in the rolling tool station, alsoincluded.
Aluminum forms a thin coating of aluminum oxide after being exposed tothe air in a little as an hour. This oxidization has a much highermelting temperature than the original aluminum material. We haveincluded a stainless steel brush for last minute cleaning.
The capacitor discharge welder is 110 volt powered. Re-charge time forthe capacitors is less than 3 seconds. The ground is on the weld gunitself. This leads to a more successful weld due to the close location.The fact that we have two ground points on either side of the weld gunalso leads to a more successful weld rate. And of course when working ona roof or the middle of a hood having to attach separate ground leadscan cause extra and unnecessary refinish time.
THE MOST COMPLETE SYSTEM AVAILABLE IS THE DF-900DX ALU-SPOT!
Everything you need is included:
Hammers, nylon & polished steel dollies, infrared temp gauge,digital heat gun, instructional CD and storage cart and 110 voltAlu-Spot welder. The DF-900DX includes everthing found in the DF-900Abut also includes a bridge puller, 3rd drawer and dust cover.
